GEN2 Garrett GTX3071R Turbo w/ .48 A/R T3 Turbine Housing w/3" GT VBAND Exit GRT-TBO-B33

Product image 1
1 / 4

GEN2 Garrett GTX3071R Turbo w/ .48 A/R T3 Turbine Housing w/3" GT VBAND Exit GRT-TBO-B33

Product Description:
    Garrett GEN2 GTX3071R dual ball bearing turbocharger with T31 inlet and 3" GT V-band outlet (w/81mm centering groove) in the .48 A/R Turbine Housing. Advanced GEN2 billet compressor wheel capable of 650HP!
Product Features:
  • Advanced aerodynamics & ultra high flow Garrett GTX GEN2 compressor wheel
  • Forged billet aluminum compressor wheel
  • Dual ball bearing CHRA rotating assembly
Product Specifications:
  • Compressor Wheel Inducer: 54mm
  • Compressor Wheel Exducer: 71mm
  • Compressor Wheel Trim: 58
  • Compressor Housing A/R: 0.60
  • Turbine Wheel Inducer: 60mm
  • Turbine Wheel Exducer: 55mm
  • Turbine Wheel Trim: 84

    INSTALLATION HARDWARE:

  • Coolant - Water Options (*Please call for assistance*)
  • Oil feed fitting with .035" restrictor: OIL-021
  • Oil drain flange: FLA-010
  • Oil drain gasket: GSK-008
  • 8mm x 1.25 (thread pitch) Stud: FST-030
  • 8mm x 1.25 (thread pitch) Locking Head Nut: FST-031

  • T3 Inlet Flange (for Turbo Manifold): FLS-038
  • T3 Inlet Gasket: GSK-005
  • V-Band "GT" 3 Inch Outlet Flange (for Downpipe): FLS-246
  • V-Band Outlet Clamp: CLA-048

    •

    NOTE: Alternate coolant and oil fittings and flanges are available.


    Compressor & Turbine Maps:



    Product Description:
      Garrett GEN2 GTX3071R dual ball bearing turbocharger with T31 inlet and 3" GT V-band outlet (w/81mm centering groove) in the .48 A/R Turbine Housing. Advanced GEN2 billet compressor wheel capable of 650HP!
    Product Features:
    • Advanced aerodynamics & ultra high flow Garrett GTX GEN2 compressor wheel
    • Forged billet aluminum compressor wheel
    • Dual ball bearing CHRA rotating assembly
    Product Specifications:
    • Compressor Wheel Inducer: 54mm
    • Compressor Wheel Exducer: 71mm
    • Compressor Wheel Trim: 58
    • Compressor Housing A/R: 0.60
    • Turbine Wheel Inducer: 60mm
    • Turbine Wheel Exducer: 55mm
    • Turbine Wheel Trim: 84

      INSTALLATION HARDWARE:

    • Coolant - Water Options (*Please call for assistance*)
    • Oil feed fitting with .035" restrictor: OIL-021
    • Oil drain flange: FLA-010
    • Oil drain gasket: GSK-008
    • 8mm x 1.25 (thread pitch) Stud: FST-030
    • 8mm x 1.25 (thread pitch) Locking Head Nut: FST-031

    • T3 Inlet Flange (for Turbo Manifold): FLS-038
    • T3 Inlet Gasket: GSK-005
    • V-Band "GT" 3 Inch Outlet Flange (for Downpipe): FLS-246
    • V-Band Outlet Clamp: CLA-048

      •

      NOTE: Alternate coolant and oil fittings and flanges are available.


      Compressor & Turbine Maps:



      $709.12

      Original: $2,363.73

      -70%
      GEN2 Garrett GTX3071R Turbo w/ .48 A/R T3 Turbine Housing w/3" GT VBAND Exit GRT-TBO-B33—

      $2,363.73

      $709.12
